Modular Fire Extinguishers

Get a Price/Quote

MOQ : 10 Units

Modular Fire Extinguishers Specification

Warranty
Yes

Shape
Spherical

Product Type
Modular Fire Extinguishers

Coating Type
Corrosion resistant powder coated (Red epoxy)

Mounting Type
Ceiling or wall mounting using adjustable bracket

Connectivity Type
Standalone (not connected to external alarms)

Operating Pressure
15 kg/cm2

Working Temperature
-30C to +60C

Technology
Modular automatic extinguishing with heat sensitive glass bulb

Material
Mild steel

Installation Type
Ceiling or wall mounted (vertical or horizontal)

Control Type
Automatic (no manual operation needed)

Fire Extinguisher Type
Modular automatic fire extinguisher

Energy Efficiency Rating
Not applicable (no power required)

Features
Automatic operation, wall/ceiling mountable, maintenance-free, rapid activation

Fire Class
A, B, C

Coverage Area
Up to 3-4 m2 per extinguisher (typical for 5 kg model)

Usage
Fire safety

Voltage
Not required (operates on heat activation)

Application
Fire protection equipment

Max Flow Rate
N/A (Discharge mechanism: automatic burst)

Diameter
130 mm

Capacity
2 kg, 5 kg, 10 kg (as per variants shown)

Pressure
15 kg/cm2

Burst Temperature
68C standard (optional 57C or 79C)

Life Span
5 years (recommended visual inspection yearly)

Container Material
Mild Steel (MS)

Extinguishing Agent
ABC Dry Powder (Monoammonium Phosphate)

Response Time
8-12 seconds after reaching burst temperature

Discharge Range
360 coverage beneath unit

Maintenance Requirement
Zero maintenance, only periodic visual check

Modular Fire Extinguishers Trade Information

Minimum Order Quantity
10 Units

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Units Per Month

Delivery Time
7-10 Days

Main Domestic Market
All India

About Modular Fire Extinguishers

Step into the spotlight of fire safety with our Popular Modular Fire Extinguishers, the ace solution for enlightened fire protection. Featuring an advanced ABC Dry Powder agent (Monoammonium Phosphate), these sensational extinguishers activate swiftly within 8-12 seconds after reaching their burst temperature-an impressive 68C standard (with optional 57C or 79C settings). Crafted from mild steel and finished with a corrosion-resistant red epoxy, each spherical unit offers up to 360 coverage. Enjoy reserve confidence with zero maintenance, rapid response, and a robust five-year lifespan-all in a maintenance-free, automatic system. Reserve yours today from a trusted Indian exporter, manufacturer, and supplier.

Features & Material Highlights of Modular Fire Extinguishers

Our Modular Fire Extinguishers stand out with their automatic operation, rapid activation, and zero-maintenance design. Built from mild steel and coated with corrosion-resistant red epoxy, these extinguishers are engineered for longevity and reliability. Used for fire safety across Class A, B, and C applications, each unit mounts easily on ceilings or walls, providing seamless integration into any space. Their spherical shape, heat-sensitive glass bulb technology, and wide coverage ensure effective and dependable protection wherever installed.

Sample Policy and Shipping Details for Modular Fire Extinguishers

Sample requests for Modular Fire Extinguishers are estimated and swiftly processed, ensuring prompt availability for inspection or evaluation. Typically dispatched from our main base, the FOB Port is in India, facilitating efficient logistics. Once ready, samples and orders are carefully handed over to our transport partners for swift delivery. We primarily cater to the main domestic markets across India, guaranteeing streamlined supply of our sensational fire safety solution to customers nationwide.

FAQ's of Modular Fire Extinguishers:

Q: How does the modular fire extinguisher activate in case of a fire?

A: The modular fire extinguisher automatically activates when the ambient temperature reaches its burst threshold (typically 68C). The heat-sensitive glass bulb breaks, instantly releasing the ABC dry powder to control the fire.

Q: What types or classes of fires can this extinguisher be used on?

A: This extinguisher is suitable for Class A (solid combustibles), Class B (flammable liquids), and Class C (gaseous fires), making it a versatile choice for broad fire protection needs.

Q: When should the extinguisher be visually inspected?

A: A visual inspection is recommended at least once a year, even though the modular system is designed for zero maintenance over its five-year lifespan.

Q: Where can these extinguishers be installed for optimal coverage?

A: These extinguishers can be ceiling or wall mounted, both vertically or horizontally, ensuring comprehensive 360-degree coverage in key areas such as server rooms, offices, warehouses, or kitchens.

Q: What is the process for exporting or obtaining a sample unit?

A: Sample requests can be made directly. Once confirmed, samples are estimated and dispatched from our facility, typically handed over at the Indian FOB Port for onward shipping.

Q: What are the key benefits of using a modular automatic fire extinguisher?

A: Key benefits include automatic activation, quick response, zero maintenance (only periodic visual checks), wide 360 coverage, wall/ceiling mounting flexibility, and no external power or manual operation required.
